DEVA DB2002 - DVB-T/T2/S/S2/C Basic Monitoring Probe

Reliable DVB-T/T2/S/S2/C monitoring capability at an excellent price

• DVB-T/T2/S/S2/C Compliant Receiver
• High-end Digital Tuner, UHF 21-60 Channel
• Up to 110 dBµV direct RF Antenna Input
• Advanced MPEG Monitoring and PID Alarms
• Detailed DVB-T/T2/S/S2/C component information
• TR 101 290 Monitoring, Priority 1, 2 and 3
• Predefined DVB channels scan or manual tune
• RF Spectrum & Constellation display
• PLP extraction and TS PLP analysis
• Built-in easy to use WEB and FTP server
• Antenna port with built-in RF attenuator
• Selectable wide range IF filter bandwidth
• Very Intuitive Navigational Menu

• Levels measurement with data history
• Spectrum analyzer allowing checking of the RF Carrier
• Service Availability Error & Service Degradation Error
• Adjustable MIN/MAX alarms for RF, SNR, BER, MER
• Alarm dispatch via E-mail, SNMP ver.2C and GPO
• Professional ASI Input and Output
• LAN port for full TCP/IP remote control and monitoring
• Protected access to the device settings
• SNTP for automatic synchronization of the built-in clock
• LAN port for full TCP/IP remote control and monitoring
• Apple and Android devices support
• Firmware updates will ensure improved operation
• Easy Installation and Setup

Continuing its mission to deliver innovative, high-performance technology, DEVA proudly presents a next-generation device that brings together the best of three worlds – terrestrial, satellite, and cable – in a single, advanced platform - DB2002. Designed with versatility and performance in mind, this all-in-one monitoring probe ensures full compliance with DVB-T/T2, DVB-S/S2, and DVB-C standards, delivering unmatched functionality and precision in one compact solution.

Built around a powerful, DSP-based high-end digital tuner, this unit guarantees accurate and dependable monitoring with detailed component information, PID alarms, and advanced MPEG transport stream decoding. It also supports comprehensive TR 101 290 and ETR290 monitoring (priorities 1, 2, and 3), ensuring full adherence to professional broadcast requirements across all signal types.

This multi-standard monitoring probe provides PLP extraction and TS PLP analysis, as well as sequential monitoring of multiple channel frequencies or PLPs. It also includes adjustable MIN/MAX alarms for RF, SNR, BER, and MER, with flexible alarm dispatch options via email, SNMP ver. 2C, or GPO.

The wide IF filter bandwidth, advanced QAM analyzer, RF Spectrum and Constellation displays allow for in-depth signal analysis and precise carrier inspection. Users can choose between predefined DVB channel scans or manual tuning for each signal type.

The device also includes **built-in storage for transport stream recording and playback**, enabling detailed diagnostics, off-line analysis, and incident review – an essential feature for quality assurance and compliance verification.

Professional-grade features such as a scalable built-in RF attenuator on the antenna port, Service Availability Error and Service Degradation Error functionality further solidify this product as a premium tool for modern broadcast operations. Full remote access is available through a LAN port with TCP/IP control, while compatibility with both Apple and Android devices ensures effortless integration into any workflow.

Firmware upgrades and protected access to device settings guarantee security and continued optimal performance, making this multi-standard monitoring tool the definitive solution for DVB-T/T2, DVB-S/S2, and DVB-C environments alike.

DB2002 is DEVA’s most cost-effective DVB-T/T2/S/S2/C monitoring solution, combining great features with an affordable price.

Specifications:
